8-CH Ethernet Relay Module, Modbus RTU/Modbus TCP Protocol, PoE Port Communication, with Various Isolation and Protection Circuits

Overview This product is an industrial 8-ch relay module controlled via Ethernet port, adopts Modbus RTU/Modbus TCP protocols, supports PoE power supply, also comes with an ABS rail-mount case. Features 1. Supports sending Modbus RTU/TCP protocol commands via Ethernet port to control relay and various devices 2. Supports Multiple Communication Modes, Adopts Modbus Protocol --Supports TCP Server / TCP Client / UDP Mode / UDP Multicast / HTTP / MQTT --Supports Modbus RTU protocol/Modbus TCP protocol 3. Multi Configuration Methods Supports software and Web Browser Configuration, Obtaining Dynamic IP Via DHCP, connecting to domain name server via DNS protocol 4. Multi Power Supply Options, Wide Range Power Input --DC Power port: directly uses a power plug for power supply; --Screw terminal: DC 7~36V wide range power input; PoE port: IEEE 802.3af PoE compliant 5. Relay Connection --Contact Rating Of The Onboard Relay Up To 10A 250VAC/30VDC --Directly Controlling 220VAC Home Appliances, Or Devices Below 30VDC 6. 4 LEDs and Network indicators for indicating the MCU status and signal transceiving status --RUN: Ethernet port indicator, blinking in 2-second cycles when Ethernet port normally working --STA: MCU indicator, blinking when the MCU normally working --TXD: TX indicator, lights up when sending data --RXD: RX indicator, lights up when receiving data 7. Application Scenarios --Control the on/off operation of household devices such as air conditioners, routers, lighting, computers, and door curtain motors, etc. --Control the on/off operation of agricultural equipments such as solenoid valves, motors, water pumps, etc. How-to-use document/User Manual ://bit.ly/45dleiL Package Content Modbus POE ETH Relay x1

• This product is an industrial 8-ch relay module controlled via Ethernet port, adopts Modbus RTU/Modbus TCP protocols, supports PoE power supply, also comes with an ABS rail-mount case.
• The Modbus POE ETH Relay is very easy to use. Due to its fast communication, stability, reliability, and safety, it is an ideal choice for industrial control equipments and/or applications with high communication requirements.
• Features flash-on, flash-off function, by passing argument to the command, it is possible to turn on the relay for a while and then close it automatically.
• Supports DC 7~36V wide range power input and PoE power supply. Supports relay control through MQTT protocol, comes with Alibaba Cloud MQTT application demo.
• Onboard Optocoupler isolation, prevent the relay from being interfered by high-voltage circuit. Reverse-proof circuit, prevent the circuit from being damaged accidentally by incorrect connection. High-quality relay, contact rating: ≤10A 250VAC/30VDC.
• Comes with Online Development Resources and Tutorials to help you get started quickly: bit.ly/45dleiL
